Container Unloading Conveyors

• Compact design & heavy-duty construction – dimensions: 81” width x 83” height
• Adjustable pivoting conveyor with side-to-side and tilt adjustments via handle controls to ergonomically position for any package location
• Operator platform supports up to 550 lbs (250 kg)
• Pressure sensing safety mat is weight-activated to ensure operator is properly positioned for operation
• High-performance 24" belt handles loads up to 165 lbs (75 kg) on a 30° incline at speeds between 86-108 feet per minute (fpm)
• Self-propelled drive system with DC drive and steering enables easy movement between docks
• Two maintenance-free batteries with a 24VDC power source for control and travel motors
• Power-saving mode has timeout feature to conserve energy
• Hand-present sensor on rotary handle must be engaged for control operation
• Emergency stop (E-Stop) buttons instantly halt all machine motion
• LED light strips enhances visibility for workers, improving safety

✅ 50% Reduction in Unloading Costs – cuts the number of man-hours needed to unload containers in half

✅ Faster Unloading Times – reduces unload times by up to 50% compared to manual methods

✅ Improves Dock Utilization

✅ Dock-to-Dock Mobility – designed for easy movement across multiple dock doors for optimized use and maximum ROI

✅ High Case Rate Efficiency – processes between 630 to 2,000 cases per hour, depending on box size and weight

✅ Optimized Workforce Utilization – fewer workers required per shift, allowing labor to be reallocated to value-added actions

✅ Increases Workplace Safety – reduces strain and injury risk by minimizing heavy lifting and repetitive motions

✅ Seamless Integration with Automation – can be connected to downstream conveyors and auto palletizers for even higher efficiency gains

• Unloading & loading Variants – two models available, one for container unloading and the other with bi-directional loading and unloading capabilities
• Flexible conveyor additions include fixed telescopic, cascading belt, and flexible powered conveyors
• Front & rear area scanners detect obstacles or personnel, slowing or stopping the machine to prevent collisions
• Safety guard rails protect workers from accidental falls while using the system
• Extended width of operator platform to 33" (standard is 22")
